DT-ASM-008 STEP 8 - Press bearing onto rotor

Tools:

• Rotor pedestal (p-2401_0002_01)
• Bearing press (p-2401_0002_02)

Installing parts:

• Bearing 6202 ZZ (013010001)

Procedure:

1. Place the rotor with the longer side of the shaft into the pedestal.
2. Use the bearing press tool to mount the bearing onto the shaft.

CAUTION

Press only on the correct bearing ring. Incorrect pressing can damage the bearing.
